Numerical Simulation of the Local Circulation of Complex Topography on the Gaoligong Mountains
-
摘要: 本文利用中尺度模式WRF（weather research and forecasting）模拟了2016年干季和湿季高黎贡山南段（腾冲—保山地区）山谷风环流，分析YSU、MYJ、MYNN3、ACM2和BouLac五种边界层参数化方案在高黎贡山复杂下垫面的适用性。研究结果表明YSU方案对温度模拟的效果最好；ACM2模拟的风速平均绝对误差最小；MYNN3方案模拟的风向绝对误差最小，YSU方案和MYJ方案模拟的风向日变化趋势与观测更加一致。高黎贡山南段地区上午09时（北京时，下同）出现谷风环流，夜间19时转为山风环流。白天多为偏南风，夜间为偏北风和偏西风。白天山顶气流辐合而山谷气流辐散，夜间相反。白天风速大于夜间。干季西风风力较弱，有利于低层局地环流的发展；而湿季受较强的偏东背景风影响时，局地环流的发展受到抑制，边界层高度也就低于干季。干季西风遇到高黎贡山，在西坡下沉并形成涡旋，西侧湍流混合充分，边界层高度高；湿季偏东风使高黎贡山西侧谷风减弱，腾冲与保山的边界层高度相差不大。Abstract: In this paper, the mesoscale weather research and forecasting (WRF) model is used to simulate mountain-valley wind circulation in the region of south Gaoligong Mountains in the dry and wet seasons, in 2016, respectively. The applicability of five layer parameterization schemes (YSU, MYJ, MYNN3, ACM2 and BouLac) under complex underlying surface of the Gaoligong Mountains is compared. The results show that the YSU scheme performs best in temperature simulation. The mean absolute error of wind speed simulated by the ACM2 scheme is the smallest, and the absolute error of wind direction simulated by the MYNN3 scheme is the smallest. The diurnal variation of wind direction simulated by the YSU and MYJ schemes is more consistent with the observation. Valley wind circulation in the southern Gaoligong Mountains appears at 0900 BJT and turns to mountain wind circulation at 1900 BJT. Southerly wind mostly prevails in the daytime and northerly and westerly wind at night. During the day, the airflow converges at the top of the mountain and diverges in the valley. At night, it is opposite. The wind speed in daytime is greater than that at night. In the dry season, the west wind is weak, which is conducive to the development of local circulation in the lower troposphere. In the wet season, the eastward background wind is strong, suppressing the development of local circulation; thus, the height of the boundary layer is shorter than that in the dry season. In the dry season, the westerly wind meets the Gaoligong Mountains, sinks on the west slope, and forms vortices, and then the turbulence on the west side is well mixed, leading to a deep boundary layer. In the wet season, the easterly wind weakens the valley wind on the west side of Gaoligong Mountains, and the height of the boundary layer between Tengchong and Baoshan is similar.
-
图 1 （a）四重模拟区域；（b）d04区域模拟地形高度（阴影）及站点位置（GLGM代表高黎贡山，T代表腾冲站，B代表保山站）；（c）d04区域MODIS 20类土地利用情况
Figure 1. (a) Model domains (d01, d02, d03, and d04); (b) terrain height of d04 and locations of two stations (GLGM is Gaoligong mountains, T is Tengchong station and B is Baoshan station); and (c) land use type of d04 from MODIS 20-class dataset
图 2 2016年12月4日08时（北京时，下同）（a）850 hPa位势高度场（单位：dagpm）和（b）海平面气压场（单位：hPa）；2016年9月27日08时850 hPa（c）位势高度场（单位：dagpm）和（d）海平面气压场（单位：hPa）（G代表高中心，D代表低中心）
Figure 2. (a) 850-hPa geopotential height field (units: dagpm) and (b) sea-level pressure field (units: hPa) at 0800 BJT 4 December 2016, (c) 850-hPa geopotential height field (units: dagpm) and (d) sea-level pressure field (units: hPa) at 0800 BJT 27 September 2016. G stands for high center, D stands for low center
图 3 2016年腾冲站（黑色）和保山站（灰色）气温（单位：℃）（a）年变化和（b）日变化
Figure 3. (a) Annual variation and (b) daily variation of air temperature (unit: °C) at Tengchong station (black) and Baoshan station (gray) in 2016
图 4 2016年腾冲站（黑色）和保山站（灰色）相对湿度（a）年变化和（b）日变化
Figure 4. (a) Annual variation and (b) daily variation of relative humidity at Tengchong station (black) and Baoshan station (gray) in 2016
图 5 2016年腾冲站（a）干季、（b）湿季和保山站（c）干季、（d）湿季风玫瑰图
Figure 5. Wind roses of (a) dry season and (b) wet season at Tengchong station and (c) dry season and (d) wet season at Baoshan station in 2016
图 6 2016年12月4日观测值与5种边界层参数化方案模拟值对比：（a）2 m温度（单位：°C）；（b）10 m风向 [单位：(°)]；（c）10 m风速日变化（单位：m s−1）；（d）10 m风速箱图
Figure 6. Comparison of observed values on 4 December 2016 with the simulated values of five boundary layer parameterization schemes: (a) 2-m temperature (units: °C); (b) 10-m wind direction [units: (°)] of daily variation; (c) 10-m wind speed (units: m s−1); (d) box chart of 10-m wind speed
图 7 模拟的2016年干季（12月4日）10 m风场（箭头，单位：m s−1）、2 m温度（阴影，单位：°C）和地形高度（等值线，单位：m）：（a）02:00；（b）10:00；（c）14:00；（d）20:00
Figure 7. Simulated the 10-m wind field (black vector, units: m s−1), 2-m temperature (shaded, units: °C), and terrain height (contour, units: m) in 2016 dry season (December 4th): (a) 0200 BJT; (b) 1000 BJT; (c) 1400 BJT; (d) 2000 BJT
图 8 2016年干季（12月4日）沿25.23°N的位温（填色，单位：K）、风场（箭头，单位：m/s）的垂直剖面（黑色阴影是海拔超过800 m的地形）：（a）02:00；（b）10:00；（c）14:00；（d）20:00
Figure 8. Vertical cross sections of potential temperature (shaded, unit: K) and wind field (vector, unit: m s−1) at 25.23°N in 2016 dry season (December 4th) (Black shadows are terrain over 800 m above sea level): (a) 0200 BJT; (b) 1000 BJT; (c) 1400 BJT; (d) 2000 BJT
图 11 模式中干季（2016年12月4日）（黑色）、湿季（2016年9月27日）（灰色）腾冲站（方框）和保山站（圆点）的边界层高度（单位：m）对比
Figure 11. Comparison of boundary layer height (units: m) between Tengchong station (square) and Baoshan station (dot) of dry season (4 December 2016) (black) and wet season (27 September 2016) (gray) in model
表 1 腾冲站和保山站全年、干季和湿季的日平均气温（单位：°C）和相对湿度
Table 1. Daily average air temperature (units: °C) and relative humidity at Tengchong and Baoshan stations throughout the year, dry and wet seasons
温度/°C 相对湿度 腾冲 保山 腾冲 保山 全年 15.77 17.67 81.45% 67.78% 干季 12.09 14.00 76.72% 62.54% 湿季 19.40 21.30 86.16% 72.96%
下载: 导出CSV
表 2 五种边界层参数化方案对温度、风向和风速的模拟值与观测值的平均绝对误差
Table 2. Mean absolute errors between observed and simulated values of air temperature, wind direction, and wind speed by the five boundary layer parameterization schemes
五种边界层参数化方案平均绝对误差 YSU MYJ MYNN3 ACM2 BouLac 温度/°C 1.41 2.39 2.47 1.41 1.50 风向/(°) 62.09 57.51 56.86 62.41 59.05 风速/m s−1 1.04 1.01 1.03 0.88 1.07
下载: 导出CSV
-
[1] Arritt R W, Pielke R A. 1986. Interactions of nocturnal slope flows with ambient winds [J]. Bound.-Layer Meteor., 37(1-2): 183−195. doi: 10.1007/BF00122763 [2] Barr S, Orgill M M. 1989. Influence of external meteorology on nocturnal valley drainage winds [J]. J. Appl. Meteor., 28(6): 497−517. doi:10.1175/1520-0450(1989)028<0497:IOEMON>2.0.CO;2 [3] Bougeault P, Lacarrère P. 1989. Parameterization of orography-induced turbulence in a Mesobeta-scale model [J]. Mon. Wea. Rev., 117(8): 1872−1890. doi:10.1175/1520-0493(1989)117<1872:POOITI>2.0.CO;2 [4] Chen F, Dudhia J. 2001. Coupling an advanced land surface-hydrology model with the Penn State NCAR MM5 modeling system. Part I: Model implementation and sensitivity [J]. Mon. Wea. Rev., 129(4): 569−585. doi:10.1175/1520-0493(2001)129<0569:CAALSH>2.0.CO;2 [5] 陈艳, 丁一汇, 肖子牛, 等. 2006. 水汽输送对云南夏季风爆发及初夏降水异常的影响 [J]. 大气科学, 30(1): 25−37. doi: 10.3878/j.issn.1006-9895.2006.01.03Chen Yan, Ding Yihui, Xiao Ziniu, et al. 2006. The impact of water vapor transport on the summer monsoon onset and abnormal rainfall over Yunnan Province in May [J]. Chinese Journal of Atmospheric Sciences (in Chinese), 30(1): 25−37. doi: 10.3878/j.issn.1006-9895.2006.01.03 [6] Clements W E, Archuleta J A, Hoard D E. 1989. Mean structure of the nocturnal drainage flow in a deep valley [J]. J. Appl. Meteor. Climatol., 28(6): 457−462. doi:10.1175/1520-0450(1989)028<0457:MSOTND>2.0.CO;2 [7] Cogliati M G, Mazzeo N A. 2006. Air flow analysis in the upper Río Negro Valley (Argentina) [J]. Atmos. Res., 80(4): 263−279. doi: 10.1016/j.atmosres.2005.09.005 [8] Doran J C. 1991. The effects of ambient winds on valley drainage flows [J]. Bound.-Layer Meteor., 55(1-2): 177−189. doi: 10.1007/BF00119333 [9] Dudhia J. 1989. Numerical study of convection observed during the winter monsoon experiment using a mesoscale two-dimensional model [J]. J. Atmos. Sci., 46(20): 3077−3107. doi:10.1175/1520-0469(1989)046<3077:NSOCOD>2.0.CO;2 [10] Gerken T, Biermann T, Babel W, et al. 2014. A modelling investigation into lake-breeze development and convection triggering in the Nam Co Lake basin, Tibetan Plateau [J]. Theor. Appl. Climatol., 117(1-2): 149−176. doi: 10.1007/s00704-013-0987-9 [11] Gross G. 1987. Some effects of deforestation on nocturnal drainage flow and local climate—A numerical study [J]. Bound.-Layer Meteor., 38(4): 315−337. doi: 10.1007/BF00120851 [12] Holt T, Raman S. 1988. A review and comparative evaluation of multilevel boundary layer parameterizations for first-order and turbulent kinetic energy closure schemes [J]. Rev. Geophys., 26(4): 761−780. doi: 10.1029/RG026i004p00761 [13] Hong S Y, Noh Y, Dudhia J. 2006. A new vertical diffusion package with an explicit treatment of entrainment processes [J]. Mon. Wea. Rev., 134(9): 2318−2341. doi: 10.1175/MWR3199.1 [14] Jiménez P A, Dudhia J. 2012. Improving the representation of resolved and unresolved topographic effects on surface wind in the WRF model [J]. J. Appl. Meteor. Climatol., 51(2): 300−316. doi: 10.1175/JAMC-D-11-084.1 [15] Jiménez P A, Dudhia J. 2013. On the ability of the WRF model to reproduce the surface wind direction over complex terrain [J]. J. Appl. Meteor. Climatol., 52(7): 1610−1617. doi: 10.1175/JAMC-D-12-0266.1 [16] Kain J S, Fritsch J M. 1993. Convective parameterization for mesoscale models: The Kain-Fritsch scheme [M]//Emanuel K A, Raymond D J. The Representation of Cumulus Convection in Numerical Models. Boston: American Meteorological Society, 165-170. doi: 10.1007/978-1-935704-13-3_16 [17] Lee J, Shin H H, Hong S Y, et al. 2015. Impacts of subgrid-scale orography parameterization on simulated surface layer wind and monsoonal precipitation in the high-resolution WRF model [J]. J. Geophys. Res. Atmos., 120(2): 644−653. doi: 10.1002/2014JD022747 [18] 李汀, 琚建华. 2013. 孟加拉湾西南季风与南海热带季风的气候特征比较 [J]. 地球物理学报, 56(1): 27−37. doi: 10.6038/cjg20130103Li Ting, Ju Jianhua. 2013. Comparison of climate features between the Southwest summer monsoon of the Bay of Bengal and the South China Sea summer monsoon [J]. Chinese J. Geophys. (in Chinese), 56(1): 27−37. doi: 10.6038/cjg20130103 [19] 李斐, 邹捍, 周立波, 等. 2017. WRF模式中边界层参数化方案在藏东南复杂下垫面适用性研究 [J]. 高原气象, 36(2): 340−357. doi: 10.7522/j.issn.1000-0534.2016.00084Li Fei, Zou Han, Zhou Libo, et al. 2017. Study of boundary layer parameterization schemes’ applicability of WRF model over complex underlying surfaces in Southeast Tibet [J]. Plateau Meteor. (in Chinese), 36(2): 340−357. doi: 10.7522/j.issn.1000-0534.2016.00084 [20] Lim K S S, Hong S Y. 2010. Development of an effective double-moment cloud microphysics scheme with prognostic Cloud Condensation Nuclei (CCN) for weather and climate models [J]. Mon. Wea. Rev., 138(5): 1587−1612. doi: 10.1175/2009MWR2968.1 [21] 刘玉洪, 张克映, 马友鑫, 等. 1996. 哀牢山(西南季风山地)空气湿度资源的分布特征 [J]. 自然资源学报, 11(4): 347−354. doi: 10.11849/zrzyxb.1996.04.008Liu Yuhong, Zhang Keying, Ma Youxin, et al. 1996. Distribution characteristics of the air humidity resource of the Ailao mountains (southwest monsoon mountainous area) [J]. J. Nat. Res. (in Chinese), 11(4): 347−354. doi: 10.11849/zrzyxb.1996.04.008 [22] 刘辉志, 洪钟祥, 桑建国. 2001. 对流边界层中过山气流的数值模拟 [J]. 气候与环境研究, 2001, 6(3): 305−311. doi: 10.3878/j.issn.1006-9585.2001.03.05Liu Huizhi, Hong Zhongxiang, Sang Jianguo. 2001. Numerical simulation of the flow over terrain on the convective boundary layer [J]. Climatic Environ. Res. (in Chinese), 2001, 6(3): 305−311. doi: 10.3878/j.issn.1006-9585.2001.03.05 [23] 刘振鑫, 刘树华, 胡非, 等. 2012. MM5和WRF对北京地区低层大气局地环流模拟能力的对比研究 [J]. 中国科学: 地球科学, 55(3): 418−427. doi: 10.1007/s11430-011-4310-2Liu Zhenxin, Liu Shuhua, Hu Fei, et al. 2012. A comparison study of the simulation accuracy between WRF and MM5 in simulating local atmospheric circulations over Greater Beijing [J]. Sci. China Earth Sci., 55(3): 418−427. doi: 10.1007/s11430-011-4310-2 [24] Mellor G L, Yamada T. 1982. Development of a turbulence closure model for geophysical fluid problems [J]. Rev. Geophys., 20(4): 851−875. doi: 10.1029/RG020i004p00851 [25] Mlawer E J, Taubman S J, Brown P D, et al. 1997. Radiative transfer for inhomogeneous atmospheres: RRTM, a validated correlated-k model for the longwave [J]. J. Geophys. Res. Atmos., 102(D14): 16663−16682. doi: 10.1029/97JD00237 [26] Nakanishi M, Niino H. 2004. An improved Mellor-Yamada level-3 model with condensation physics: Its design and verification [J]. Bound.-Layer Meteor., 112(1): 1−31. doi: 10.1023/B:BOUN.0000020164.04146.98 [27] Pleim J E. 2007. A Combined local and nonlocal closure model for the atmospheric boundary layer. PartⅡ: Application and evaluation in a mesoscale meteorological model [J]. J. Appl. Meteor. Climatol., 46(9): 1396−1409. doi: 10.1175/JAM2534.1 [28] Prasad K B R R H, Srinivas C V, Rao T N, et al. 2017. Performance of WRF in simulating terrain induced flows and atmospheric boundary layer characteristics over the tropical station Gadanki [J]. Atmos. Res., 185: 101−117. doi: 10.1016/j.atmosres.2016.10.020 [29] 齐瑛, 傅抱璞. 1992. 过山气流与地形形状 [J]. 南京大学学报, 28(4): 633−643.Qi Ying, Fu Baopu. 1992. Airflow over mountain and mountain shape [J]. Journal of Nanjing University (Natural Science Edition) (in Chinese), 28(4): 633−643. [30] Schmidli J, Rotunno R. 2012. Influence of the valley surroundings on valley wind dynamics [J]. J. Atmos. Sci., 69(2): 561−577. doi: 10.1175/JAS-D-11-0129.1 [31] 屠妮妮, 何光碧, 张利红. 2012. 不同边界层和陆面过程参数化方案对比分析 [J]. 高原山地气象研究, 32(3): 1−8. doi: 10.3969/j.issn.1674-2184.2012.03.001Tu Nini, He Guangbi, Zhang Lihong. 2012. Numerical studies of different planet boundary layer parameterization and land surface model parameterization [J]. Plateau and Mountain Meteorology Research (in Chinese), 32(3): 1−8. doi: 10.3969/j.issn.1674-2184.2012.03.001 [32] 王瑾, 张镭, 王腾蛟, 等. 2012. 兰州附近山谷典型日环流特征对比分析 [J]. 干旱气象, 30(2): 169−177. doi: 10.3969/j.issn.1006-7639.2012.02.003Wang Jin, Zhang Lei, Wang Tengjiao, et al. 2012. Comparative analysis of mountain-valley wind circulation characteristics over semi-arid areas nearby Lanzhou [J]. Journal of Arid Meteorology (in Chinese), 30(2): 169−177. doi: 10.3969/j.issn.1006-7639.2012.02.003 [33] Xie B, Fung J C H, Chan A, et al. 2012. Evaluation of nonlocal and local planetary boundary layer schemes in the WRF model [J]. J. Geophys. Res. Atmos., 117(D12): D12103. doi: 10.1029/2011JD017080 [34] 徐嘉行, 李良敏, 刘敏蓉. 1984. 盛夏云南大—暴雨与季风活动的关系 [J]. 云南大学学报(3): 53−62.Xu Jiaxing, Li Liangmin, Liu Minrong. 1984. The relationship between the rainstorms over Yunnan Province and the activity of summer monsoon during summer [J]. Journal of Yunnan University (in Chinese)(3): 53−62. [35] 叶笃正. 1956. 小地形对于气流的影响 [J]. 气象学报, 27(3): 243−262. doi: 10.11676/qxxb1956.018Ye Duzheng. 1956. Topographical effect on the airflow [J]. Acta Meteor. Sinica (in Chinese), 27(3): 243−262. doi: 10.11676/qxxb1956.018 [36] 尹相玉. 2014. 基于WRF模式的济南地区大气边界层特征模拟研究 [D]. 山东师范大学硕士学位论文.Yin Xiangyu. 2014. The numerical simulation of atmospheric boundary layer in Ji’nan by using WRF [D]. M. S. thesis (in Chinese), Shandong Normal University. [37] Zängl G. 2009. The impact of weak synoptic forcing on the valley-wind circulation in the Alpine Inn Valley [J]. Meteor. Atmos. Phys., 105(1-2): 37−53. doi: 10.1007/s00703-009-0030-y [38] 张小培, 银燕. 2013. 复杂地形地区WRF模式四种边界层参数化方案的评估 [J]. 大气科学学报, 36(1): 68−76. doi: 10.3969/j.issn.1674-7097.2013.01.008Zhang Xiaopei, Yin Yan. 2013. Evaluation of the four PBL schemes in WRF Model over complex topographic areas [J]. Trans. Atmos. Sci. (in Chinese), 36(1): 68−76. doi: 10.3969/j.issn.1674-7097.2013.01.008 -
