A Case Study on Summer Precipitation Process in the Central Tianshan Area Using Multi-radar Observation and Model Simulation
-
摘要: 基于微雨雷达、Ka波段云雷达、C波段天气雷达和微波辐射计等仪器的观测资料对2019年7月27日中天山地区一次局地对流云降水过程的精细结构及演变过程进行分析,并结合WRF高分辨率数值模式模拟结果研究了热力不稳定结构及风切变层对云发展的影响。结果表明:此次降水过程中天山北坡区域受到地形热力强迫,形成爬坡气流,并与翻越天山山脉的偏南气流在局部形成对流;雷达观测发现,由于天山山区受到高空西风的控制,局地产生的对流云团不足以突破中天山北坡上空的风速较大的西南气流或偏西气流,低层的偏北气流被高层气流夹带而转向形成风切变层。降水发生后,低层对流云团被限制在风切变层以下,云顶平整且高度较低,风切变层对对流云团存在明显的抑制作用。通过分析模拟结果,此次降水过程中风切变层对中天山北坡降水云的发展及热力不稳定变化影响十分重要,高层西南风对相当位温的平流输送使得风切变层上空更倾向于热力不稳定,同时使其下方更倾向于热力稳定从而抑制低层对流而促进高层对流的发展。当低层对流云团强度不足以突破其上空因垂直风切变导致的稳定层结,对流便会被局限于垂直风切变层以下,使得降水强度减弱。Abstract: The fine vertical structure and evolution of orographic precipitation in the middle Tianshan area was analyzed using measurements taken from a micro rain radar, Ka-band cloud radar, and microwave radiometer. In addition, a high-resolution simulation is conducted to analyze the thermal instability and wind shear layer influence on cloud generation. The observations reveal that the precipitation was generated owing to the convergence between the southwesterly wind flying across the mountain ridge and the northerly wind generated by the thermal forcing in the terrain. Because the observed convective updraft was not strong enough, the low-level northerly flow turned southward as it approached the high-level southwesterly wind, resulting in strong wind shear. Following the precipitation, the low-level convective clouds were constrained to remain below the wind shear layer, and the cloud tops were generally flat and low, indicating that the wind shear layer significantly inhibited the convection. The model simulation suggests that the influence of wind shear on developing precipitation clouds and the change in the thermal instability on the northern slope of the Central Tianshan Mountains during this precipitation is crucial. The advective transport of equivalent potential temperature, caused by the action of upper-level southerly winds, was responsible for the layer above the wind shear layer becoming thermally unstable and the layer underneath it becoming thermally stable, thereby suppressing low-level convection and promoting upper-level convection. If low-level convective updrafts were not strong enough to break through the stable laminar junction caused by vertical wind shear, convection would be constrained to remain below the vertical wind shear layer, preventing intense precipitation.
-
Key words:
- Central Tianshan /
- Multi-radar observation /
- Wind shear /
- Potential divergence
-
图 1 中天山北坡地形及观测仪器所在位置,黄色圆圈表示C波段天气雷达扫描范围(半径75 km),红色实线表示云雷达扫描范围
Figure 1. Topography topography of the northern slope of central Tianshan Mountain and the location of the observation instruments; the yellow circle indicates the C-band weather radar scanning range, and the solid red line indicates the cloud radar scanning range
图 3 2019年7月(a、b)26日20:00、(c、d)27日14:00 500 hPa(左列)和700 hPa(右列)ERA5再分析资料位势高度场(实线,单位:gpm)及风场分布,棕色实线为槽线,红色三角为观测站点所在位置
Figure 3. Distributions of geopotential height field (solid line, units: gpm) and wind field from ERA5 reanalysis data at 500 hPa (left column) and 700 hPa (right column) at (a, b) 2000 BJT (Beijing time) on July 26 and1400 BJT on July 27,2019. The dark red curves indicate the trough and the red triangle is the location of the station
图 4 2019年7月27日17:00(a)ERA5再分析资料800 hPa流场分布和(b)沿观测站点东西剖面WRF模拟的风场垂直分布,红线为图4b剖面位置。2019年7月27日(c)16:45~17:00和(d)17:00~17:15 FY-4A卫星可见光通道云图,红色三角为观测站点位置
Figure 4. (a) Distributions of ERA5 reanalysis data 800 hPa flow field and (b) the vertical distributions of wind simulated using WRF field along the east–west profile of the station at 1700 BJT July, 2019. FY-4A satellite true color at (c) 1645 BJT–1700 BJT and (d) 1700 BJT–1715 BJT, the red line is the position of the profile in fig.4b and the red triangle is the position of the station
图 5 2019年7月27日06:00~17:00微波辐射计观测(a)温度(单位:°C)、(b)相对湿度和(c)水汽密度(单位:g m−3)廓线分布
Figure 5. Distributions of (a) temperature profile (units: °C), (b) relative humidity profile, and (c) water vapor concentration profile (units: g m−3) from microwave radiometer observations from 0600 BJT to 1700 BJT on July 27, 2019
图 6 2019年7月27日(a、b)16:04和(c、d)17:03 C波段雷达第三层扫描雷达反射率因子(左列)及多普勒径向速度(右列)分布红色圆点为C波段天气雷达位置,红色三角为Ka波段云雷达位置,仰角为2.4°
Figure 6. Distributions of reflectivity factors (left column) and radial velocity (right column) at (a, b) 1604 BJT, (c, d) 1703 BJT July 27, 2019, the red dot is the C-band weather radar position, and the red triangle is the Ka-band cloud radar position, elevation angle=2.4°
图 9 2019年7月27日(a、b、c)16:36、(d、e、f)16:46、(g、h、i)16:56、(j、k、l)17:06和(m、n、o)17:17 Ka波段云雷达RHI扫描雷达反射率因子(左列)、多普勒径向速度(中间列)及速度谱宽(右列)的垂直结构
Figure 9. Ka-band cloud radar RHI scan reflectivity factors (left colu), Doppler radial velocity (middle column) and width spectrum (right column) vertical structure at (a, b, c) 1636 BJT, (d, e, f) 1646 BJT, (g, h, i) 1656 BJT, (j, k, l) 1706 BJT, and (m, n, o) 1717 BJT on July 27, 2019
图 10 2019年7月27日(a)16:26、(b)16:36、(c)16:46、(d)16:56和(e)17:06 Ka波段云雷达反射率因子概率分布(其中黑色实线为雷达反射率因子中位数线),以及(f)雷达反射率因子中位数廓线
Figure 10. Distributions of Ka-band cloud radar reflectivity factors contoured frequency using altitude diagrams at (a) 1626 BJT, (b) 1636 BJT, (c) 1646 BJT, (d) 1656 BJT, and (e) 1706 BJT on July 27, 2019, where the solid black line is the median radar reflectivity factor line, and (f) median radar reflectivity factor profiles
图 11 2019年7月27日(a)16:00、(b)16:30、(c)17:00和(d)17:30沿图4a红线相当位温(等值线,单位:K)、水汽混合比(彩色阴影,单位:g kg−1)以及风场(灰色箭头)的南北方向剖面。横坐标原点为云雷达所在位置
Figure 11. North–south profiles for equivalent potential temperature (contours, units: K), water vapor mixing ratio (colored shading, units: g kg−1), and wind field (gray arrows) along the red line of Fig. 4a at (a) 1600 BJT, (b) 1630 BJT, (c) 1700 BJT, and (d) 1730 BJT on July 27, 2019. 0 on the x-axis indicates the location of the cloud radar
图 12 2019年7月27日(a、b、c)16:00、(d、e、f)16:30和(g、h、i)17:00沿图4a红线位势散度m$ \mathrm{m} $(左列,彩色阴影)、$ m $的分量$ {m}_{bc} $(中间列,彩色阴影)、$ m $的分量$ {m}_{bt} $(右列,彩色阴影、)的南北方向剖面,单位:10−6 K m−1 s−1,灰色阴影为地形
Figure 12. North–south profiles of potential dispersion m (left column, colored shading), component $ {m}_{bc} $ (middle column, colored shading), and component $ {m}_{bt} $ (right column, colored shading) along the red line of Fig. 4a at (a, b, c)1600 BJT, (d, e, f) 1630 BJT, and (g, h, i) at 1700 BJT on July 27, 2019, units: 10−6 K m−1 s−1,the grey shading is terrain
表 1 观测仪器主要指标和性能
Table 1. Main indicators and performance of the observation instruments
名称 频率/波长 时间分辨率 空间分辨率 探测产品 C波段天气雷达 5.47 GHz/5.48 cm 6 min 150 m 反射率因子、径向速度、速度谱宽 Ka波段云雷达 35 GHz/8.59 mm 5 min 150 m 反射率因子、径向速度、速度谱宽 微雨雷达 24.23 GHz/1.238 cm 30 s 100 m 反射率因子、径向速度、速度谱宽 微波辐射计 — 2 min 50 m、100 m和250 m 温度、湿度、水汽 表 2 模式参数设置
Table 2. Configuration of the model
三层嵌套网格 D01 D02 D03 水平空间分辨率(格点数) 9 km
(600×500)3 km
(511×400)1 km
(697×535)垂直层数 33层 积云参数化方案 Grell-Freitas方案 微物理方案 Thompson方案 长波辐射方案 RRTMG方案 短波辐射方案 RRTMG方案 陆面过程方案 Noah方案 近地面层方案 Monin-Obukhov(Janjic Eta)方案 边界层方案 MYJ方案 A1 参数化组合试验方案
试验名称 边界层方案 云微物理方案 MThompson MYJ方案 Thompson方案 MLin MYJ方案 Lin方案 MWSM6 MYJ方案 WSM6方案 BThompson BL方案 Thompson方案 BLin BL方案 Lin方案 BWSM6 BL方案 WSM6方案 -
[1] Aikins J, Friedrich K, Geerts B, et al. 2016. Role of a cross-barrier jet and turbulence on winter orographic snowfall [J]. Mon. Wea. Rev., 144(9): 3277−3300. doi: 10.1175/MWR-D-16-0025.1 [2] Bougeault P. and P. Lacarrere 1989. Parameterization of Orography-induced Turbulence in a Mesobeta-Scale Model [J]. Mon. Wea. Rev., 117: 1872−1890. doi: 10.1175/1520-0493(1989)117<1872:POOITI>2.0.CO;2 [3] Bougeault P, Binder P, Buzzi A, et al. 2001. The MAP special observing period [J]. Bull. Amer. Meteor. Soc., 82(3): 433−462. doi: 10.1175/1520-0477(2001)082<0433:TMSOP>2.3.CO;2 [4] Bousquet O, Smull B F. 2003. Observations and impacts of upstream blocking during a widespread orographic precipitation event [J]. Quart. J. Roy. Meteor. Soc., 129(588): 391−409. doi: 10.1256/qj.02.49 [5] Chen S.-H. and W.-Y Sun 2002. A one-dimensional time dependent cloud model [J]. J. Meteor. Sc. Japan, 80(1): 99−118. doi: 10.2151/jmsj.80.99 [6] 陈湉茹. 2017. 天山地区夏季降水的小时尺度特征 [D]. 中国气象科学研究院硕士学位论文.Che Tianru. 2017. The characteristics of hourly precipitation in Tianshan Mountain during summer [D]. M. S. thesis (in Chinese), Chinese Academy of Meteorological Sciences. [7] 洪延超, 黄美元, 王首平. 1984. 梅雨云系中亮带不均匀性的理论探讨 [J]. 大气科学, 8(2): 197−204. doi: 10.3878/j.issn.1006-9895.1984.02.10Hong Yanchao, Huang Meiyuan, Wang Shouping. 1984. A theoretical study on inhomogeneity of bright band in Mei–Yü frontal cloud system [J]. Chinese Journal of Atmospheric Sciences (Scientia Atmospherica Sinica) (in Chinese), 8(2): 197−204. doi: 10.3878/j.issn.1006-9895.1984.02.10 [8] Houze R A Jr, Medina S. 2005. Turbulence as a mechanism for orographic precipitation enhancement [J]. J. Atmos. Sci., 62(10): 3599−3623. doi: 10.1175/JAS3555.1 [9] Hong S.-Y and J.-O. J. Lim 2006. The WRF single-moment 6-class microphysics scheme(WSM6) [J]. J. Korean Meteor. Soc., 42: 129−151. [10] 胡汝骥. 2004. 中国天山自然地理 [M]. 北京: 中国环境科学出版社.Hu Ruji. 2004. Physical Geography of the Tianshan Mountains in China (in Chinese) [M]. Beijing: China Environmental Science Press. [11] 黄昕, 周玉淑, 冉令坤, 等. 2021. 一次新疆伊犁河谷特大暴雨过程的环境场及不稳定条件分析 [J]. 大气科学, 45(1): 148−164. doi: 10.3878/j.issn.1006-9895.1912.19219Huang Xin, Zhou Yushu, Ran Lingkun, et al. 2021. Analysis of the environmental field and unstable conditions on a rainstorm event in the Ili valley of Xinjiang [J]. Chinese Journal of Atmospheric Sciences (in Chinese), 45(1): 148−164. doi: 10.3878/j.issn.1006-9895.1912.19219 [12] Janic Z I. 1994. The Step-Mountain Eta Coordinate Model: Further developments of the convection, viscous sublayer, and turbulence closure schemes [J]. Mon. Wea. Rev., 122: 927−945. doi: 10.1175/1520-0493(1994)122<0927:TSMECM>2.0.CO;2 [13] 姜彩莲, 郭琪, 李建刚, 等. 2013. 天山北坡一次暴雨天气成因初探 [J]. 干旱区资源与环境, 27(6): 160−166. doi: 10.13448/j.cnki.jalre.2013.06.033Jiang Cailian, Guo Qi, Li Jiangang, et al. 2013. A preliminary analysis of formational causes of a heavy rain in North Slope of Tianshan Mountain [J]. Journal of Arid Land Resources and Environment (in Chinese), 27(6): 160−166. doi: 10.13448/j.cnki.jalre.2013.06.033 [14] 连钰, 杨军, 朱莉莉, 等. 2017. 夏季东天山中段一次强对流天气过程的数值模拟 [J]. 大气科学学报, 40(5): 663−674. doi: 10.13878/j.cnki.dqkxxb.20161031002Lian Yu, Yang Jun, Zhu Lili, et al. 2017. A numerical study of the severe convective precipitation processes over the middle section of the eastern Tianshan Mountains during the summer seasons [J]. Transactions of Atmospheric Sciences (in Chinese), 40(5): 663−674. doi: 10.13878/j.cnki.dqkxxb.20161031002 [15] Liu C H, Ikeda K, Thompson G, et al. 2011. High-resolution simulations of wintertime precipitation in the Colorado Headwaters region: Sensitivity to physics parameterizations [J]. Mon. Wea. Rev., 139(11): 3533−3553. doi: 10.1175/MWR-D-11-00009.1 [16] 刘晓阳, 张培昌, 顾松山. 1992. 用折叠线跟踪算法退除多卜勒速度折叠 [J]. 南京气象学院学报, 15(4): 493−499. doi: 10.13878/j.cnki.dqkxxb.1992.04.006Liu Xiaoyang, Zhang Peichang, Gu Songshan. 1992. Tracking aliased line to dealiase Doppler velocity [J]. Journal of Nanjing Institute of Meteorology (in Chinese), 15(4): 493−499. doi: 10.13878/j.cnki.dqkxxb.1992.04.006 [17] 陆风, 张晓虎, 陈博洋, 等. 2017. 风云四号气象卫星成像特性及其应用前景 [J]. 海洋气象学报, 37(2): 1−12. doi: 10.19513/j.cnki.issn2096-3599.2017.02.001Lu Feng, Zhang Xiaohu, Chen Boyang, et al. 2017. FY-4 geostationary meteorological satellite imaging characteristics and its application prospects [J]. Journal of Marine Meteorology (in Chinese), 37(2): 1−12. doi: 10.19513/j.cnki.issn2096-3599.2017.02.001 [18] 马淑红, 席元伟. 1997. 新疆暴雨的若干规律性 [J]. 气象学报, 55(2): 239−248. doi: 10.11676/qxxb1997.025Ma Shuhong, Xi Yuanwei. 1997. Some regularities of storm rainfall in Xinjiang, China [J]. Acta Meteorologica Sinica (in Chinese), 55(2): 239−248. doi: 10.11676/qxxb1997.025 [19] 彭亮, 陈洪滨, 李柏. 2011. 模糊逻辑法在3mm云雷达反演云中水凝物粒子相态中的应用 [J]. 遥感技术与应用, 26(5): 655−663.Peng Liang, Chen Hongbin, Li Bai. 2011. An application of fuzzy logic method to cloud hydrometeor classifications using the ARM WACR data [J]. Remote Sensing Technology and Application (in Chinese), 26(5): 655−663. [20] 史玉光, 孙照渤, 杨青. 2008. 新疆区域面雨量分布特征及其变化规律 [J]. 应用气象学报, 19(3): 326−332.Shi Yuguang, Sun Zhaobo, Yang Qing. 2008. Characteristics of area precipitation in Xinjiang region with its variations [J]. Journal of Applied Meteorological Science (in Chinese), 19(3): 326−332. [21] 史玉光, 孙照渤. 2008. 新疆水汽输送的气候特征及其变化 [J]. 高原气象, 27(2): 310−319.Shi Yuguang, Sun Zhaobo. 2008. Climate characteristics of water vapor transportation and its variation over Xinjiang [J]. Plateau Meteorology (in Chinese), 27(2): 310−319. [22] Shupe M D. 2007. A ground-based multisensor cloud phase classifier [J]. Geophys. Res. Lett., 34(22): L22809. doi: 10.1029/2007GL031008 [23] Smith R B, Schafer P, Kirshbaum D J, et al. 2009. Orographic precipitation in the tropics: Experiments in Dominica [J]. J. Atmos. Sci., 66(6): 1698−1716. doi: 10.1175/2008JAS2920.1 [24] Stoelinga M T, Hobbs P V, Mass C F, et al. 2003. Improvement of microphysical parameterization through observational verification experiment [J]. Bull. Amer. Meteor. Soc., 84(12): 1807−1826. doi: 10.1175/BAMS-84-12-1807 [25] Thompson G., Field P. R., Rasmussen R M, et al. 2008. Explicit Forecastes of Winter Precipitation Using an Improved Bulk Microphysics Scheme. Part Ⅱ: Implementation of a New Snow Parameterization. Mon. Wea. Rev., 136: 5095–5115. doi:10.1175/2008MWR2387.1 [26] 王秀荣, 徐祥德, 王维国. 2007. 西北地区春、夏季降水的水汽输送特征 [J]. 高原气象, 26(4): 749−758.Wang Xiurong, Xu Xiangde, Wang Weiguo. 2007. Charateristic of spatial transportation of water vapor for northwest China′s rainfall in spring and summer [J]. Plateau Meteorology (in Chinese), 26(4): 749−758. [27] Wang Z E, Sassen K. 2001. Cloud type and macrophysical property retrieval using multiple remote sensors [J]. J. Appl. Meteorol., 40(10): 1665−1682. doi: 10.1175/1520-0450(2001)040<1665:CTAMPR>2.0.CO;2 [28] 吴举秀, 魏鸣, 王以琳. 2015. 利用毫米波测云雷达反演层状云中过冷水 [J]. 干旱气象, 33(2): 227−235. doi: 10.11755/j.issn.1006-7639(2015)-02-0227Wu Juxiu, Wei Ming, Wang Yilin. 2015. Retrieval of the supercooled water in stratiform clouds based on millimeter-wave cloud radar [J]. Journal of Arid Meteorology (in Chinese), 33(2): 227−235. doi: 10.11755/j.issn.1006-7639(2015)-02-0227 [29] 吴举秀, 魏鸣, 苏涛, 等. 2017. W波段和Ka波段云雷达探测回波对比分析 [J]. 海洋气象学报, 37(2): 57−64. doi: 10.19513/j.cnki.issn2096-3599.2017.02.007Wu Juxiu, Wei Ming, Su Tao, et al. 2017. Comparison of the echoes detected by W-band and Ka-band cloud radars [J]. Journal of Marine Meteorology (in Chinese), 37(2): 57−64. doi: 10.19513/j.cnki.issn2096-3599.2017.02.007 [30] 杨莲梅. 2003. 南亚高压突变引起的一次新疆暴雨天气研究 [J]. 气象, 29(8): 21−25. doi: 10.3969/j.issn.1000-0526.2003.08.005Yang Lianmei. 2003. Research on a case of Heavy Rain in Xinjiang from South Asia high abnormity [J]. Meteorological Monthly (in Chinese), 29(8): 21−25. doi: 10.3969/j.issn.1000-0526.2003.08.005 [31] 姚俊强, 杨青, 黄俊利, 等. 2012. 天山山区及周边地区水汽含量的计算与特征分析 [J]. 干旱区研究, 29(4): 567−573. doi: 10.13866/j.azr.2012.04.018Yao Junqiang, Yang Qing, Huang Junli, et al. 2012. Computation and analysis of water vapor content in the Tianshan Mountains and peripheral regions, China [J]. Arid Zone Research (in Chinese), 29(4): 567−573. doi: 10.13866/j.azr.2012.04.018 [32] 张佃国, 王烁, 郭学良, 等. 2020. 基于机载Ka波段云雷达和粒子测量系统同步观测的积层混合云对流泡特征 [J]. 大气科学, 44(5): 1023−1038. doi: 10.3878/j.issn.1006-9895.2004.19185Zhang Dianguo, Wang Shuo, Guo Xueliang, et al. 2020. The properties of convective generating cells embedded in the stratiform cloud on basis of airborne Ka-band precipitation cloud radar and droplet measurement technologies [J]. Chinese Journal of Atmospheric Sciences (in Chinese), 44(5): 1023−1038. doi: 10.3878/j.issn.1006-9895.2004.19185 [33] 张景, 周玉淑, 沈新勇, 等. 2019. 2016年"7.19"京津冀极端降水系统的动热力结构及不稳定条件分析 [J]. 大气科学, 43(4): 930−942. doi: 10.3878/j.issn.1006-9895.1812.18231Zhang Jing, Zhou Yushu, Shen Xinyong, et al. 2019. Evolution of dynamic and thermal structure and instability condition analysis of the extreme precipitation system in Beijing–Tianjin–Hebei on July 19 2016 [J]. Chinese Journal of Atmospheric Sciences (in Chinese), 43(4): 930−942. doi: 10.3878/j.issn.1006-9895.1812.18231 [34] 张正勇, 何新林, 刘琳, 等. 2015. 中国天山山区降水空间分布模拟及成因分析 [J]. 水科学进展, 26(4): 500−508. doi: 10.14042/j.cnki.32.1309.2015.04.006Zhang Zhengyong, He Xinlin, Liu Lin, et al. 2015. Spatial distribution of rainfall simulation and the cause analysis in China’s Tianshan Mountains area [J]. Advances in Water Science (in Chinese), 26(4): 500−508. doi: 10.14042/j.cnki.32.1309.2015.04.006 [35] 赵传成, 丁永建, 叶柏生, 等. 2011. 天山山区降水量的空间分布及其估算方法 [J]. 水科学进展, 22(3): 315−322. doi: 10.14042/j.cnki.32.1309.2011.03.014Zhao Chuancheng, Ding Yongjian, Ye Baisheng, et al. 2011. Spatial distribution of precipitation in Tianshan Mountains and its estimation [J]. Advances in Water Science (in Chinese), 22(3): 315−322. doi: 10.14042/j.cnki.32.1309.2011.03.014 [36] 周围, 包云轩, 冉令坤, 等. 2018. 一次飑线过程对流稳定度演变的诊断分析 [J]. 大气科学, 42(2): 339−356. doi: 10.3878/j.issn.1006-9895.1712.17126Zhou Wei, Bao Yunxuan, Ran Lingkun, et al. 2018. Diagnostic analysis of convective stability evolution during a squall line process [J]. Chinese Journal of Atmospheric Sciences (in Chinese), 42(2): 339−356. doi: 10.3878/j.issn.1006-9895.1712.17126 -
