Comparative Analysis of Precipitation Characteristics of the Westward Typhoon Cases “Bilis” and “Sepat” during Landfall under Different Monsoon Intensities
-
摘要: 本文使用CMORPH卫星反演降水资料、日本再分析资料JRA-55和FY-2E卫星的云顶亮温（TBB）资料等，选取了登陆前后季风强度差异很大、路径形似且登陆后均在湘南地区引发强降水的0604号强热带风暴“碧利斯”和0708号台风“圣帕”，从对流发展的不稳定能量来源、抬升机制和环境风垂直切变方面进行对比，研究季风气流如何影响台风降水强度和分布。分析表明，在下垫面和地形基本一致的情况下，两台风导致强降水的主要成因不同，主要体现在引发对流并使对流维持的主要影响因子不同。与强季风背景密切相关的低层强烈辐合抬升和对流不稳定层结是导致“碧利斯”暴雨形成的主要因素，而弱季风背景下“圣帕”的暴雨则主要是局地地形抬升和斜压不稳定导致的。而且与“圣帕”降水相比，“碧利斯”降水存在明显的非对称性，季风气流可间接通过改变环境风垂直切变导致这种降水分布特征。Abstract: From the aspects of unstable energy sources for convective development, uplifting mechanism, and vertical shear of environmental wind, this work studies how the monsoon flow affects the intensity and distribution of typhoon precipitation. For this, CMORPH (CPC morphing technique) satellite data product obtained from the CPC’s (Climate Prediction Center) morphing technique, JRA-55 (55-year-old Japanese reanalysis products), and TBB (blackbody brightness temperature) data from the FY-2E (FengYun-2E) satellite were used, and the strong monsoon-influenced case 0604 “Bilis” and weak monsoon-influenced case 0708 “Sepat”, which have similar paths and cause heavy precipitation in the southern area of the Hunan Province after landfall, were selected. The analysis showed that with a similar underlying surface and topography, the main causes of heavy precipitation of the two cases are different. This is mainly reflected in the factors that induce and maintain convection. The strong convergent updraft and convective instability under the strong monsoon background were the main factors leading to the heavy rain of “Bilis”, while the rainstorm of “Sepat” was mainly due to the local orographic lift and baroclinic instability under the weak monsoon background. Moreover, the precipitation of “Bilis” was obviously asymmetric, which indicated that the monsoon flow could lead to asymmetric precipitation by changing the vertical shear of the environmental wind indirectly.
-
Key words:
- Typhoon /
- Monsoon /
- Precipitation distribution /
- Convective
-
图 1 强热带风暴Bilis：（a）2006年7月15日06时（协调世界时，下同）500 hPa位势高度场（黑色实线，单位：dagpm）和850 hPa风场（黑色箭头，单位：m s−1）；（b）2006年7月11～19日850 hPa纬向风（单位：m s−1）沿115°E的剖面。台风Sepat：（c）2007年8月19日06时500 hPa位势高度场（黑色实线，单位：dagpm）和850 hPa风场（黑色箭头，单位：m s−1）；（d）2007年8月15～23日850 hPa纬向风（单位：m s−1）沿115°E的剖面。图a、c中，红色线段表示台风路径，红色台风标志表示台风位置，蓝色粗实线表示588 dagpm
Figure 1. Super typhoon Bilis: (a) 500-hPa geopotential height (black solid lines, units: dagpm) and 850-hPa wind (black arrows, units: m s−1) at 0600 UTC on 15 July 2006; (b) cross section of 850-hPa zonal wind (units: m s−1) along 115°E from 11 July to 19 July 2006. Super typhoon Sepat: (c) 500-hPa geopotential height (black solid lines, units: dagpm) and 850-hPa wind (black arrows, units: m s−1) at 0600 UTC on 19 August 2007; (d) cross section of 850-hPa zonal wind (units: m s−1) along 115°E from 15 August to 23 August 2007. In Figs. a, c, the red lines indicate the typhoon path, the red typhoon signs indicate the typhoon position, and the thick blue solid lines represent 588 dagpm
图 2 （a）2006年7月14日18时Bilis的200 hPa位势高度场（黑色实线，单位：dagpm）、风场（蓝色箭头，单位：m s−1）、散度场（阴影，单位：10−6 s−1），（b）2007年8月20日18时Sepat的200 hPa高度场（黑色实线，单位：dagpm）、风场（蓝色箭头单位：m s−1）、散度场（阴影，单位：10−6 s−1）
Figure 2. (a) 200-hPa geopotential height (black solid lines, units: dagpm), wind (blue arrows, units: m s−1), and divergence (shadings, units: 10−6 s−1) of Bilis at 1800 UTC on 14 July 2006; (b) 200-hPa geopotential height (black solid lines, units: dagpm), wind (blue arrows, units: m s−1), and divergence (shadings, units: 10−6 s−1) of Sepat at 1800 UTC on 20 August 2007
图 3 Bilis（a）2006年7月14日06时（登陆时）、（b）2006年7月15日18时（登陆后36 h），Sepat（c）2007年8月18日18时（登陆时），（d）2007年8月20日06时（登陆后36 h）850 hPa水汽通量（阴影、箭头，单位：g s−1 hPa−1 cm−1）
Figure 3. 850-hPa water vapor fluxes (shadings, arrows, units: g s−1 hPa−1 cm−1) of Bilis (a) at 0600 UTC (landfall) on 14 July 2006; (b) at 1800 UTC (36 h after landfall) on 15 July 2006; 850-hPa water vapor fluxes (shadings, arrows, units: g s−1 hPa−1 cm−1) of Sepat (c) at 1800 UTC (landfall) on 18 August 2007; (d) at 0600 UTC (36 h after landfall) on 20 August 2007
图 4 （a）Bilis 2006年7月14日09时至15日09时和（b）Sepat 2007年8月19日07时至22日07时平均降水强度 [单位：mm/(12 h)，由于Sepat降水持续时间长，过程降水量更大，但为了突出Bilis单位时间降水更强，因此图示阶段降水量已换算成每12 h降水量]。灰色线段为台风路径；线段上的数字，以2006071406为例，表示2006年7月14日06时
Figure 4. Average precipitation intensity [units: mm/(12 h)] of (a) Bilis from 0900 UTC on 14 July 2006 to 0900 UTC on 15 July 2006, and (b) Sepat from 0700 July on 19 August 2007 to 0700 July on 22 August 2007. The precipitation of Sepat lasts for a longer time, the process precipitation of Sepat is larger, but to highlight the hourly precipitation of Bilis, the process precipitation has been converted into precipitation per 12 h. The gray line indicates the typhoon path. The numbers on gray lines, taking 2006071406 for example, represent 0600 UTC on 14 July 2006
图 5 （a）2006年7月14日18时Bilis逐小时累计降水量（单位：mm），（b）2007年8月20日18时Sepat逐小时累计降水量（单位：mm），（c）湖南、江西和广东三省地形分布。图a、b中，线段A、B为图8的垂直剖线
Figure 5. Hourly precipitation (units: mm) of (a) Bilis at 1800 UTC on 14 July 2006, (b) Sepat at 1800 UTC on 20 August 2007, (c) topographic map of the Hunan, Jiangxi, and Guangdong provinces. In Figs. a, b, lines A and B are the vertical section lines in Fig. 8
图 6 Bilis 2006年7月（a）13日00时、（b）14日01时、（c）14日16时，Sepat 2007年8月（d）18日06时、（e）19日05时、（f）19日13时逐时相当黑体温度（单位：°C）
Figure 6. Blackbody temperature (units: °C) of Bilis at (a) 0000 UTC on 13 July 2006, (b) 0100 UTC on 14 July 2006, and (c) 1600 UTC on 14 July 2006. Blackbody temperature (units: °C) of Sepat at (d) 0600 UTC on 18 August 2007, (e) 0500 UTC on 19 August 2007, and (f) 1300 UTC on 19 August 2007
图 7 （a）Bilis 2006年7月14日18时沿25.5°N和（b）Sepat 2007年8月20日18时沿26°N假相当位温（等值线，单位：K），合成风矢量[箭头，u（纬向风，单位：m s−1）、−10ω（垂直风，单位：−10−1 Pa s−1）]的高度—经度剖面。红色三角形表示暴雨中心位置
Figure 7. Height–longitude profiles of pseudo-equivalent potential temperature (contours, units: K) and composite wind [arrows, u (zonal wind, units: m s−1), −10ω (vertical wind, units: −10−1 Pa s−1)] of along (a) 25.5°N at 1800 UTC on 14 July 2006, and (b) 26°N at 1800 UTC on 20 August 2007. The red triangles represent the centers of the rainstorm
图 8 （a）Bilis 2006年7月14日18时沿图5a中线段A和（b）Sepat 2007年8月20日18时沿图5b中线段B的合成风矢量[箭头，u、v（经向风，单位：m s−1）、−10ω（垂直风，单位：−10−1 Pa s−1）]，散度（阴影，单位：10−6 s−1）的垂直剖面。红色和蓝色三角形分别表示暴雨和台风中心位置
Figure 8. Composite wind [arrows, u, v (meridional wind, units: m s−1), −10ω (vertical wind, units: −10−1 Pa s−1)] of u, v (meridional wind), −10ω (vector, units: m s−1) and divergences (shadings, units: 10−6 s−1) along (a) line A in Fig. 5a for Bilis at 1800 UTC on 14 July 2006 and (b) line B in Fig. 5b for Sepat at 1800 UTC on 20 August 2007. The red and blue triangles indicate the location of the rainstorm and typhoon center, respectively
图 9 （a）Bilis 2006年7月14日18时、（b）Sepat 2007年8月20日18时850 hPa假相当位温（单位：K）。红色三角形表示降水中心位置
Figure 9. 850-hPa pseudo-equivalent potential temperature (units: K) for (a) Bilis at 1800 UTC on 14 July 2006 and (b) Sepat 1800 UTC on 20 August 2007. The red triangles indicate the locations of the rainstorm
图 10 （a）2006年7月14日12时Bilis和（b）2007年8月19日00时Sepat逐时降水量（阴影，单位：mm）、距台风中心10°×10°范围内850 hPa风场（箭头，单位：m s−1）。紫（黑）色粗箭头表示850 hPa（200 hPa）平均环境风矢量，红色箭头表示VWS
Figure 10. Hourly precipitation (shadings, units: mm) and 850-hPa wind (arrows, units: m s−1) in the range of 10°×10° from the typhoon center of (a) Bilis at 1200 UTC on 14 July 2006, and (b) Sepat at 0000 UTC on 19 August 2007. The bold purple (black) arrows represent 850-hPa (200-hPa) average environmental wind vector, and red arrows represent VWS (vertical wind shear)
-
[1] 陈联寿, 丁一汇. 1979. 西太平洋台风概论 [M]. 北京: 科学出版社, 1–26.Chen Lianshou, Ding Yihui. 1979. An Introduction to the Western Pacific Typhoons (in Chinese) [M]. Beijing: Science Press, 1–26. [2] 陈联寿, 许映龙. 2017. 中国台风特大暴雨综述 [J]. 气象与环境科学, 40(1): 3−10. doi: 10.16765/j.cnki.1673-7148.2017.01.001Chen Lianshou, Xu Yinglong. 2017. Review of typhoon very heavy rainfall in China [J]. Meteorological and Environmental Sciences (in Chinese), 40(1): 3−10. doi: 10.16765/j.cnki.1673-7148.2017.01.001 [3] Chen S S, Knaff J A, Marks Jr F D. 2006. Effects of vertical wind shear and storm motion on tropical cyclone rainfall asymmetries deduced from TRMM [J]. Mon. Wea. Rev., 134(11): 3190−3208. doi: 10.1175/MWR3245.1 [4] Chen L S, Li Y, Cheng Z Q. 2010. An overview of research and forecasting on rainfall associated with landfalling tropical cyclones [J]. Adv. Atmos. Sci., 27(5): 967−976. doi: 10.1007/s00376-010-8171-y [5] Chien F C, Liu Y C, Lee C S. 2008. Heavy rainfall and southwesterly flow after the leaving of typhoon Mindulle (2004) from Taiwan [J]. J. Meteor. Soc. Japan, 86(1): 17−41. doi: 10.2151/jmsj.86.17 [6] Corbosiero K L, Molinari J. 2002. The effects of vertical wind shear on the distribution of convection in tropical cyclones [J]. Mon. Wea. Rev., 130(8): 2110−2123. doi:10.1175/1520-0493(2002)130<2110:TEOVWS>2.0.CO;2 [7] Gao S Z, Meng Z Y, Zhang F Q, et al. 2009. Observational analysis of heavy rainfall mechanisms associated with severe tropical storm Bilis (2006) after its landfall [J]. Mon. Wea. Rev., 137(6): 1881−1897. doi: 10.1175/2008MWR2669.1 [8] 何金海, 丁一汇, 高辉, 等. 2001. 南海夏季风建立日期的确定与季风指数 [M]. 北京: 气象出版社, 123pp.He Jinhai, Ding Yihui, Gao Hui, et al. 2001. Establishment of the South China Sea Summer Monsoon Establishment Date and Monsoon Index (in Chinese) [M]. Beijing: China Meteorological Press, 123pp. [9] 黄明策, 姚才, 李菁. 2005. 低空急流对广西热带气旋特大暴雨的影响及概念模式 [J]. 广西气象, 26(1): 5−9. doi: 10.3969/j.issn.1673-8411.2005.01.002Huang Mingce, Yao Cai, Li Jing. 2005. Analysis of the low-level jet (LLJ) effect on typhoon torrential rain in Guangxi and the conceptual model [J]. Journal of Guangxi Meteorology (in Chinese), 26(1): 5−9. doi: 10.3969/j.issn.1673-8411.2005.01.002 [10] Joyce R J, Janowiak J E, Arkin P A, et al. 2004. CMORPH: A method that produces global precipitation estimates from passive microwave and infrared data at high spatial and temporal resolution [J]. Journal of Hydrometeorology, 5(3): 487−503. doi:10.1175/1525-7541(2004)005<0487:CAMTPG>2.0.CO;2 [11] 李崇银, 张利平. 1999. 南海夏季风活动及其影响 [J]. 大气科学, 23(3): 257−266. doi: 10.3878/j.issn.1006-9895.1999.03.01Li Chongyin, Zhang Liping. 1999. Summer monsoon activities in the South China Sea and its impacts [J]. Chinese Journal of Atmospheric Sciences (in Chinese), 23(3): 257−266. doi: 10.3878/j.issn.1006-9895.1999.03.01 [12] 李英, 陈联寿, 王继志. 2004. 登陆热带气旋长久维持与迅速消亡的大尺度环流特征 [J]. 气象学报, 62(2): 167−179. doi: 10.3321/j.issn:0577-6619.2004.02.004Li Ying, Chen Lianshou, Wang Jizhi. 2004. The diagnostic analysis on the characteristics of large scale circulation corresponding to the sustaining and decaying of tropical cyclone after it’s landfall [J]. Acta Meteorologica Sinica (in Chinese), 62(2): 167−179. doi: 10.3321/j.issn:0577-6619.2004.02.004 [13] 李瑞, 李本亮, 胡鹏, 等. 2014. 环境垂直风切变对0509号台风“麦莎”的影响分析 [J]. 海洋学研究, 32(2): 14−22.Li Rui, Li Benliang, Hu Peng, et al. 2014. Effects of environmental vertical wind shear on Typhoon Matsa (0509) [J]. Journal of Marine Sciences (in Chinese), 32(2): 14−22. [14] 梁建茵, 吴尚森. 2002. 南海西南季风爆发日期及其影响因子 [J]. 大气科学, 26(6): 829−844. doi: 10.3878/j.issn.1006-9895.2002.06.11Liang Jianyin, Wu Shangsen. 2002. A study of southwest monsoon onset date over the South China Sea and its impact factors [J]. Chinese Journal of Atmospheric Sciences (in Chinese), 26(6): 829−844. doi: 10.3878/j.issn.1006-9895.2002.06.11 [15] 卢珊, 王黎娟, 管兆勇, 等. 2012. 低纬季风涌影响登陆台风“榴莲”(0103)和“碧利斯”(0604)暴雨增幅的比较 [J]. 大气科学学报, 35(2): 175−185. doi: 10.13878/j.cnki.dqkxxb.2012.02.006Lu Shan, Wang Lijuan, Guan Zhaoyong, et al. 2012. Comparison of impacts of low-latitude monsoon surge on the enhanced rainstorm from landing typhoons Durian and Bilis [J]. Transactions of Atmospheric Sciences (in Chinese), 35(2): 175−185. doi: 10.13878/j.cnki.dqkxxb.2012.02.006 [16] Palmer C K, Barnes G M. 2002. The effects of vertical wind shear as diagnosed by the NCEP/NCAR reanalysis data on Northeast Pacific hurricane intensity [C]//Proceedings of the 25th Conference on Hurricanes and Tropical Meteorology. San Diego: American Meteorological Society, 122–123. [17] 潘志祥, 叶成志, 刘志雄, 等. 2008. “圣帕”、“碧利斯”影响湖南的对比分析 [J]. 气象, 34(7): 41−50. doi: 10.7519/j.issn.1000-0526.2008.07.007Pan Zhixiang, Ye Chengzhi, Liu Zhixiong, et al. 2008. Comparisons analysis of rainstorm processes in Hunan Province caused by typhoon Bilis and Sepat [J]. Meteorological Monthly, 34(7): 41−50. doi: 10.7519/j.issn.1000-0526.2008.07.007 [18] 任福民, 王小玲, 董文杰, 等. 2007. 登陆中国初、终热带气旋的变化 [J]. 气候变化研究进展, 3(4): 224−228. doi: 10.3969/j.issn.1673-1719.2007.04.007Ren Fumin, Wang Xiaoling, Dong Wenjie, et al. 2007. Changes in the first-landfall and last-landfall tropical cyclones in China [J]. Advances in Climate Change Research (in Chinese), 3(4): 224−228. doi: 10.3969/j.issn.1673-1719.2007.04.007 [19] Rogers R, Chen S Y, Tenerelli J, et al. 2003. A numerical study of the impact of vertical shear on the distribution of rainfall in hurricane Bonnie (1998) [J]. Mon. Wea. Rev., 131(8): 1577−1599. doi: 10.1175//2546.1 [20] Wang B, Lin H, Zhang Y, et al. 2004. Definition of South China Sea monsoon onset and commencement of the East Asia summer monsoon [J]. J. Climate., 17(4): 699−710. doi: 10.1175/2932.1 [21] Wang D H, Li X F, Tao W K. 2010. Responses of vertical structures in convective and stratiform regions to large-scale forcing during the landfall of severe tropical storm Bilis (2006) [J]. Adv. Atmos. Sci., 27(1): 33−46. doi: 10.1007/s00376-009-8139-y [22] 吴恒强. 2002. 影响广西的热带气旋与热带季风的某些关系 [J]. 气象, 28(9): 27−32. doi: 10.3969/j.issn.1000-0526.2002.09.006Wu Hengqiang. 2002. Relationships between tropical cyclone affecting Guangxi and tropical monsoon [J]. Meteorological Monthly (in Chinese), 28(9): 27−32. doi: 10.3969/j.issn.1000-0526.2002.09.006 [23] 叶成志, 李昀英, 黎祖贤. 2009. 两次严重影响湖南的登陆台风水汽场特征数值模拟 [J]. 高原气象, 28(1): 98−107. doi: 10.1016/s1003-6326(09)60084-4Ye Chengzhi, Li Yunying, Li Zuxian, et al. 2009. Numerical study on the water vapor transports of the two landfalling cyclones affecting Hunan Province [J]. Plateau Meteorology, 28(1): 98−107. doi: 10.1016/s1003-6326(09)60084-4 [24] 余贞寿, 陈敏, 叶子祥, 等. 2009. 相似路径热带气旋“海棠” (0505)和“碧利斯”(0604)暴雨对比分析 [J]. 热带气象学报, 25(1): 37−47. doi: 10.3969/j.issn.1004-4965.2009.01.005Yu Zhenshou, Chen Min, Ye Zixiang, et al. 2009. Analysis of rainstorm associated with similar track tropical cyclones “HAITANG” (0505) and “BILIS” (0604) [J]. Journal of Tropical Meteorology (in Chinese), 25(1): 37−47. doi: 10.3969/j.issn.1004-4965.2009.01.005 [25] 张恒德, 孔期. 2007. 0604号强热带风暴碧利斯异常强降水过程的诊断分析 [J]. 气象, 33(5): 42−48. doi: 10.3969/j.issn.1000-0526.2007.05.006Zhang Hengde, Kong Qi. 2007. Diagnostic analysis of severe tropical storm Bilis heavy rain event [J]. Meteorological Monthly (in Chinese), 33(5): 42−48. doi: 10.3969/j.issn.1000-0526.2007.05.006 [26] 周海光. 2008. 强热带风暴碧利斯(0604)引发的特大暴雨中尺度结构多普勒雷达资料分析 [J]. 大气科学, 32(6): 1289−1308. doi: 10.3878/j.issn.1006-9895.2008.06.05Zhou Haiguang. 2008. 3D structure of the heavy rainfall caused by BILIS (0604) with Doppler radar data [J]. Chinese Journal of Atmospheric Sciences (in Chinese), 32(6): 1289−1308. doi: 10.3878/j.issn.1006-9895.2008.06.05 [27] 周玉淑, 邓涤菲, 李建通. 2014. 登陆热带气旋Bilis(0604)暴雨增幅与风场结构变化 [J]. 大气科学, 38(3): 563−576. doi: 10.3878/j.issn.1006-9895.2013.12220Zhou Yushu, Deng Difei, Li Jiantong. 2014. Rainstorm amplification of typhoon Bilis (0604) and its wind structural change [J]. Chinese Journal of Atmospheric Sciences (in Chinese), 38(3): 563−576. doi: 10.3878/j.issn.1006-9895.2013.12220 -
